木工加工棚一般需根據施工組織計劃，還需考慮部分鋼筋原材料、加工后鋼筋的周轉及堆放。下面來講講木工加工棚的6點基本使用常識。

Generally, the woodworking shed shall be constructed according to the construction organization plan, and the turnover and stacking of some raw materials and processed steel bars shall also be considered. Now let's talk about 6 basic common sense of woodworking shed.

1.木工棚分為敞開式和封閉式，凈空高度不低于2900mm。

1. The woodworking shed is divided into open type and closed type, and the clearance height is not less than 2900mm.

2.塔吊回轉半徑內和建筑物周邊的加工棚應設置雙層硬質防護,上下層間距不小于600mm。

2. The processing shed within the slewing radius of the tower crane and around the building shall be provided with double-layer hard protection, and the space between the upper and lower layers shall not be less than 600mm.

3.加工車間地面需硬化,立柱與地面連接牢固。

3. The ground of the processing workshop needs to be hardened, and the column is firmly connected with the ground.

4.加工棚應配置滅火器、驗收牌、警示牌等圖牌。

4. The processing shed shall be equipped with fire extinguishers, acceptance boards, warning boards and other drawing boards.

5.敞開式木工棚立柱、桁架主梁均采用150×150mm方鋼，桁架連桿均用50×150mm方鋼,立柱基礎澆筑700×700×700mm混凝土,預埋300×300×12mm鋼板。

5. The column and truss main beam of the open woodworking shed are 150 × 150mm square steel, 50 for truss connecting rod × 150mm square steel, 700 column foundation pouring × seven hundred × 700mm concrete, embedded 300 × three hundred × 12mm steel plate.

6.各種型材及構配件規格為參考值，具體規格應根據當?shù)仫L(fēng)荷載、雪荷載進行核算，編制專項方案。如遇臺風應采取防風措施，可設置纜風繩。

6. The specifications of various profiles and components and fittings are reference values. The specific specifications shall be calculated according to the local wind load and snow load, and a special scheme shall be prepared. In case of typhoon, windproof measures shall be taken, and wind rope can be set.

關于木工加工棚的6點基本使用常識問題的相關內容便是這樣了，您對此有什么不理解的地方歡迎來我們網站http://gdinte.com.cn咨詢了解！

Here are the six basic common sense questions about woodworking shed. If you have any questions, please come to our website http://gdinte.com.cn Ask about it!
